Metal Stair Stringers

The 27 rule is a traditional stair layout guideline used to evaluate the ergonomic relationship between riser height and tread depth. While traditional formulas offer general guidance, our custom steel stringers are engineered to comply with specific local building codes for riser height and tread depth, ensuring structural safety and code compliance for residential or commercial installations.

Manufacturing metal stair stringers begins with custom design consultation and engineering shop drawings tailored to the space. Structural steel components, such as steel tubes, channels, or plates, are precisely cut and fabricated. Treads and support plates are welded or assembled, followed by quality control and optional powder coating or galvanizing for interior or exterior durability.

Steel stair stringer sizing varies by configuration and layout requirements. Common structural profiles include 2x6, 4x6, and 6x8 steel rectangular tubes, 6x6 square tubes, 4-inch or 6-inch round steel tubes, and steel channels or structural plates. Tube dimensions and plate thicknesses, such as 3/8-inch tread plates, are selected based on stair span, design style, and traffic requirements.

While generic premade stringers exist for standard utility builds, custom-fabricated metal stair stringers provide superior structural integrity, precision fit, and aesthetic appeal. Custom fabrication allows stringers to accommodate exact floor-to-floor heights, specialized configurations like straight, curved, or winder layouts, and diverse architectural tread materials including wood, stone, glass, and steel.

Metal stair stringers can be custom fabricated in single stringer, double stringer, and side stringer configurations. These support straight-line runs, L-shaped layouts, U-shaped switchback or scissor stairs, and geometric winder treads. They can also be engineered as curved staircases or combined with spiral stairs to match specific residential or commercial interior and exterior architectural designs.

Metal stair stringers accommodate virtually any tread material to match interior or exterior aesthetics. Supported tread options include wood, stone, glass, cement, ceramic tile, rubber, and diamond plate steel. Treads are supported by heavy-duty steel plates, angle iron carriers, or pan-style assemblies engineered to handle demanding residential and commercial foot traffic.
